EPSON XP-5100 XP-5105 XP-5150 XP-5155 Parts Manual
In stock
SKU
EP-XP5100-PM
$1.20
- Email with download link immediately
- Files without viruses
- PDF format manual
- Allow high-definition printing
| Manual Name | EPSON XP-5100 XP-5105 XP-5150 XP-5155 Parts Manual |
|---|---|
| Format | |
| PDF Archive | 3.64M |
| Pages | 3 |
| Brand | EPSON |
| Type | SERVICE or PARTS MANUAL |
| Compatible Model | Epson XP-5100 Series |
****** The following content is not included in the PDF manual, please use it online ******
| Article | Reference | Description |
| 1717906 | 100 | STACKER,MAIN,FASF |
| 1718363 | 101 | HOUSING,LEFT |
| 1737239 | 102 | HOUSING,FRONT |
| 1719332 | 103 | COVER,HINDGE,SC |
| 1737235 | 104 | HOUSING,RIGHT |
| 1743687 | 105 | PANEL ASSY.,CG29,EPPI |
| 1814610 | 105 | PANEL ASSY.,CG29,EPPI |
| 1837893 | 105 | PANEL ASSY.,CG29,EPPI |
| 1865109 | 105 | PANEL ASSY.,CG29,EPPI |
| 1732848 | 106 | Cover,Ink,Eject |
| 1737234 | 107 | HOUSING,UPPER,REAR,FASF,IC |
| 1745518 | 108 | LABEL,MODEL,NAME,XP-5100 |
| 2192274 | 200 | BOARD ASSY.,MAIN |
| 2214096 | 200 | BOARD ASSY.,MAIN |
| 2195631 | 300 | BOARD ASSY.,POWER SUPPLY |
| 2192161 | 350 | WIRELESS LAN USB MODULE |
| 1748865 | 352 | CARD SLOT ASSY,CG29,EPPI,ASP |
| 1767046 | 501 | PICK UP ASSY.,CG20,EPPI |
| 1790715 | 503 | ASF BANK ASSY.,CG20,EPPI |
| 1801803 | 503 | ASF BANK ASSY.,CG20,EPPI |
| 1572114 | 504 | FRAME,BANK |
| 1720079 | 505 | PAPER GUIDE,GIZA,FRAME,BANK |
| 1741784 | 506 | PAPER GUIDE,CENTER,FRAME,BANK |
| 1717908 | 507 | POROUS PAD,PAPER GUIDE,LOWER |
| 1743613 | 508 | PAPER GUIDE FRONT ASSY.,CG29,EPPI |
| 2182527 | 509 | MOTOR ASSY.,CR |
| 1748636 | 510 | CARRIAGE ASSY.,CG29,EPPI,ASP |
| 2181521 | 511 | BOARD ASSY.,SNS |
| 2186445 | 512 | CABLECSIC |
| 2186560 | 513 | CABLE,HEAD |
| 1759427 | 514 | DETECTOR PE ASSY,CG22,EPPI |
| 1724136 | 515 | PGU RIGHT ASSY,CG19,EPPI |
| 1864167 | 515 | PGU RIGHT ASSY,CG19,EPPI |
| 1724137 | 516 | PGU LEFT ASSY,CG19,EPPI |
| 1864168 | 516 | PGU LEFT ASSY,CG19,EPPI |
| 1548480 | 517 | EXTENSION SPRING,1.41 |
| 1717899 | 518 | SCALE,PF |
| 1750924 | 519 | SCALE,CR |
| 2181519 | 524 | BOARD ASSY.,ENCODER |
| 1717912 | 526 | GORUNDING PLATE,HEAD,CR |
| 1720073 | 528 | POROUS PAD,PAPER GUIDE,LOWER,B |
| 1720075 | 529 | POROUS PAD,PAPER GUIDE,LOWER,C |
| 1720076 | 530 | POROUS PAD,PAPER GUIDE,LOWER,D |
| 1766269 | 531 | HOLDER STARWHEEL M1 ASSY .,CG28,EPPI |
| 2150454 | 532 | BOARD ASSY.,SUB |
| 2186444 | 533 | CABLE,PIS |
| 1717901 | 534 | ROLLER,EJ |
| 1832107 | 534 | ROLLER,EJ |
| 2186983 | 541 | MOTOR,ASSY,PF,B |
| 1717883 | 542 | ROLLER,PF |
| 1767047 | 701 | HOLDER DAMPER ASSY.,CG23,EPPI |
| 1717987 | 702 | RACK,DUMPER,SC |
| 1752917 | 703 | CASSETTE ASSY.,CG21,EPPI |
| 1717922 | 704 | COVER,CABLE,HEAD |
| 1748644 | 710 | IS M1 ASSY.,CG29,EPPI,ASP |
| 1786089 | 712 | DUPLEX ASSY,CG29,EPPI,ASP |
| 1741765 | 723 | HOLDER,CONNECTOR,CSIC,IS |
| 1743690 | 724 | HOLDER,BOARD ASSY.,CG29,EPPI |
| 1738271 | 725 | GUIDE,FFC |
| 2184967 | 726 | CONNECTOR,CSIC |
| 2185770 | 727 | CABLE,CSIC,INK EJECT,B |
| 1760357 | 729 | POROUS PAD,CR,u1 |
| 2192842 | 800 | SCANNER UNIT,CG29,EPPI, ASP |
| 1735632 | 801 | COVER DOCUMENT ASSY.,CG22,EPPI,ASP |
| 1718119 | 802 | COVER,ASF |
| 1876516 | 802 | COVER,ASF |
